Details
Airflow m³/h
85m³/h
Applicable Area
Bathroom, Toilet
Collection Name
XF100
Extraction Rate
23L/s
Extractor Fan Type
Axial
Fan Diameter
4 Inch
Finish/Colour
White
GTIN (Barcode)
5020953550044
Humidistat
Yes
IP Rating
IP24
Installation Kit
Yes
MPN
XF100H
Min Voltage
220V
Mounting Options
Ceiling, Wall
Number of Speeds
1
Power Consumption
14W
SELV (Low Voltage)
Yes
Timer
Yes
Voltage
240V
Dimensions
Height
163mm
Length
75mm
Lip Depth
30mm
Weight
0.01kg
Width
163mm
Manrose 100mm Axial Extractor Fan with Humidity Control - XF100H
SKU: XF100H
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 10+ | £28.62 | Save 2% |
| 20+ | £28.04 | Save 4% |
| 30+ | £27.45 | Save 6% |
You may also need
Product Information
This comprehensive range of 4" fans from Manrose have been designed for Wall, Ceiling or Window mounting for use in bathrooms, toilets or kitchens. Quiet and efficient the 100mm (4") series has an impressive extract rate of 85m³/hr, 23 litres per second. The units are are all manufactured using high ABS thermoplastics for strength, durability, aesthetics and easy cleaning. XF100 Series designed for wall mounting (pullcord version wall mounting only) through 100mm (4") diameter flexible or rigid pipes or Manrose low profile, flat channel ducting systems.
- Single phase consuming 15 Watts
- Designed for wall, ceiling or window mounting, this comprehensive range offers a wide selection of models for use in bathrooms and toilets.
- Quiet and efficient, the 100mm (4") series has an impressive extract rate of 85m3/hr, 23 litres per second, and is available in the eleven options detailed opposite.
- The units are all manufactured using high ABS thermoplastics for strength and durability, aesthetics and easy cleaning.
- Power is provided by a single phase induction motor with pre-oiled bearings for a long, maintenance- free life.
- Designed to comply with the Building Regulations on Ventilation (F1).
- Mounting: Wall
- Noise: 41.0 dB(A)
- Hole Size: 4"
- Type of Extractor: Axial
- Number of Speeds: 1
- Extraction Rate: 23 litres per second
- XF/WF100 Series 85m3/hr, 23 l/s
- 100mm (4")
- Maximum pressure: 20 p.a.
- Fan speed: 2400 r.p.m.
- Sound volume: 41.0 dB(A)
- Maximum operating temperature: 40ºC.
- Dimensions: Height: 163mm x Width: 163mm x Depth: 75mm
