Details
GTIN (Barcode)
5026992040232
MPN
SRG1123
Surge Protected
Yes
Voltage
230V
Wired
No
Dimensions
Depth
82mm
Height
94mm
Weight
0.05kg
Width
36mm
Downloads
srg1123-datasheet
Lewden 50kA Single Pole + E Type 1+2+3 Surge Protector - SRG1123
SKU: SRG1123
Product Information
Lewden 50kA Single Pole + E Type 1+2+3 Surge Protector - SRG1123
This Lewden surge protector is suitable for use in TN-C-S (PME) / TNS / TT network systems.
- IEC61643-11
- Type: Type 1&2
- Rated Operating Voltage: 230V
- Frequency: 50/60Hz
- Signalling Contact: Yes
- Voltage Protection Level (Up) L/N: <1.3kV
- Max Continuous Operating Voltage: 280 VAC
- Number of Modules: 2
- Dimensions (HWD): 94 x 36 x 82mm
