Details
Applicable Area
Bathroom, Commercial, Laundry Room, Office, Toilet, Warehouse
Collection Name
ACM
Domestic/Commercial
Domestic, Commercial
Duct Diameter
150mm
Extraction Rate
145L/s
Extractor Fan Type
Inline
Fan Diameter
6 Inch
Finish/Colour
White
GTIN (Barcode)
5015135093990
IP Rating
IP44
MPN
17106010
Mounting Options
Ceiling
Max Noise Level
36dB
Number of Speeds
3
Power Consumption
48W
Voltage
240V
Dimensions
Depth
350mm
Height
256mm
Width
200mm
Downloads
17106010-product-manual
Vent-Axia ACM150 Mixed Flow 150mm (6") In-line Extractor Fan - 17106010
SKU: 17106010
You save: £87.25
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 10+ | £171.01 | Save 2% |
| 20+ | £167.52 | Save 4% |
| 30+ | £164.03 | Save 6% |
Details
Applicable Area
Bathroom, Commercial, Laundry Room, Office, Toilet, Warehouse
Collection Name
ACM
Domestic/Commercial
Domestic, Commercial
Duct Diameter
150mm
Extraction Rate
145L/s
Extractor Fan Type
Inline
Fan Diameter
6 Inch
Finish/Colour
White
GTIN (Barcode)
5015135093990
IP Rating
IP44
MPN
17106010
Mounting Options
Ceiling
Max Noise Level
36dB
Number of Speeds
3
Power Consumption
48W
Voltage
240V
Dimensions
Depth
350mm
Height
256mm
Width
200mm
Downloads
17106010-product-manual
Product Information
The Vent Axia ACM150 Mixed Flow 150 mm In‑Line Extractor Fan (17106010) is a robust and powerful in-line ventilation unit designed for heavier duty installations. With a 150 mm (6″) duct diameter, it supports high airflow rates (up to approximately 522 m³/h or ~145 l/s in its higher speed setting) which makes it well suited for larger rooms, commercial spaces, or environments requiring longer duct runs.
Constructed with a mixed-flow impeller, the ACM150 generates significantly more static pressure—around 2.5 times that of conventional axial fans—allowing it to push air effectively through longer or more complex duct systems. The casing is finished in a wipe-clean polymer, rated to IP44 for protection in many indoor settings, and the motor assembly features a three-speed selectable motor with a rotating chassis and removable motor core for easier installation and maintenance.
From an installer’s perspective, the ACM150 offers flexible mounting options (horizontal or vertical), detachable spigots for straightforward duct connection, and complies with standard ambient temperature expectations (up to +50 °C).Its noise output is relatively low given its capacity, with typical values around 29-36 dB(A) at 3 m, depending on the speed setting
